Sprinkler Heads
Cold Solid problem settlement before flush over in case of fire through real fire test Shock withstand structure of Iron ball supported type Low assembly load Because O-ring sealing method minimizes the assembly load, the stress generated inside the head is small and it is very safe design. Our Flush Sprinkler Head is an innovative and totally new structure with high-quality special coating and O-ring on the nozzle part and 8 bearing balls on disassembly part. Leakage or watering is an unthinkable sprinkler head unless the sprinkler head is operated by temperature and the breakdown section is completely broken or the head itself is not completely broken. It is a literally shockproof type sprinkler head which can not be seen in other products due to its stable structure developed by our company. Downward SSP sprinkler head Downward SSP sprinkler head Downward SSP sprinkler head Downward SSP sprinkler head Downward SSP sprinkler head Downward SSP sprinkler head * Flush Sprinkler Head : SSP sprinkler
72℃ Early response type
Product overview : Flush sprinkler head
Notice: Undefined offset: 20 in /home/kwangun/public_html/html/_module/product/view.html on line 29
Product Characteristics
Product Specififcation
Item No.
Display
TemperatureHeat Sensitivity
Water Quantity(ℓ/min)
Effective Watering Radius(m)
Mounting Direction
Protection Cap Color
AE72-Q80C
72℃
Early response type
80
2.6
Yellow-green
AE105-Q80C
105℃
Early response type
80
2.6
Transparent
AE72-Q50C
72℃
Early response type, Residential fire sprinkler head
50
2.6
Red
AE105-Q50C
105℃
Early response type, Residential fire sprinkler head
2.6
Pink
AE72-M80C
72℃
Standard response type
80
2.3
Green
AE105-M80C
105℃
Standard response type
80
2.3
Blue
